Industrial Use Soundproof 500kVA Cummins Diesel Power Generator
Product Description
Configuration Spec.
1) Powered by brand new original water cooled Diesel Engine.
2) Brand new STAMFORD, LEROY SOMER or GENLITEC single bearing 3 phase Alternator with IP23 and H insulation class.
3) Original 50ºC radiator with Engine driven fan mounted on skid.
4) Delixi or Chint branded case circuit breaker mounted.
5) Heavy-duty fabricated steel based frame with built-in fuel tank for at least 8 hours continuous running.
6) Complete set mounted on a based frame with anti-vibration mountings.
7) Industrial 9 dB muffler exhaust system with blexible connects and bellows.
8) Based frame with fuel, oil and coolant drain cocks for easy maintenance.
9) 12/24V DC electric start system with free maintain battery & smartgen brand battery charger.
10) Set mounted automatic control panel, with SMARTGEN brand AMF controller module for automatic start & stop.
11) Test report of generator, set of drawings and manuals.
12) CE, ISO9001 approved
1) Powered by brand new original water cooled Diesel Engine.
2) Brand new STAMFORD, LEROY SOMER or GENLITEC single bearing 3 phase Alternator with IP23 and H insulation class.
3) Original 50ºC radiator with Engine driven fan mounted on skid.
4) Delixi or Chint branded case circuit breaker mounted.
5) Heavy-duty fabricated steel based frame with built-in fuel tank for at least 8 hours continuous running.
6) Complete set mounted on a based frame with anti-vibration mountings.
7) Industrial 9 dB muffler exhaust system with blexible connects and bellows.
8) Based frame with fuel, oil and coolant drain cocks for easy maintenance.
9) 12/24V DC electric start system with free maintain battery & smartgen brand battery charger.
10) Set mounted automatic control panel, with SMARTGEN brand AMF controller module for automatic start & stop.
11) Test report of generator, set of drawings and manuals.
12) CE, ISO9001 approved
1200kw genset 150kva Diesel Generator
Diesel generator Details | |
| Model | XHX-1200GF |
| Power | 1200kw/1500kva |
| Frequency | 50Hz/60Hz |
| Voltage | 4000/230v(voltage can be customized) |
| Optional Type | Open/soundproof/trailer |
| Size of Open Type | 5600*2150*2600mm |
| Weight of Open type | 11000kg |
| With Diesel Engine | |
| Brand&model | KTA50-GS8 |
| Standby Power | 1429kw |
| Cylinders | 16 in V arrangement |
| Bore*Stroke | 159*159mm |
| Displacement | 50L |
| Lubrication Oil Capacity | 204L |
| Fuel Consumption at 100% Load | 205g/kw.h |
| Speed Governor | Electronic |
| With Alternator | |
| Optional Brands | Stamford/Leroy Somer/Mecc Alte/Marathon |
| Exciter type | Single bearing,brushless,Self-excited |
| Power factor | 0.8 |
| Voltage adjust range | ≥5% |
| Insulation Grade | H |
| Protection Grade | IP23 |
| With Controller | |
| Optional brands | Deepsea/ComAp/Smartgen |
Product Categories : CUMMINS ENGINE DIESEL GENERATOR SETS
